| Place of Origin: | China |
| Brand Name: | HSTECH |
| Certification: | CE |
| Model Number: | HS-BD4 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden package, with foam |
| Delivery Time: | 5~7 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per week |
| Product Name: | LED Bulb Glue Dispenser | Power Supply: | AC220V/50~60Hz/200W |
|---|---|---|---|
| Max Dispensing Diameter: | 160mm(two Station),110mm(four Station) | Motor Speed: | Max 300mm/s |
| Repeat Accuracy: | ±0.02mm | Warranty: | 1 Year |
| Application: | LED Bulb, LED Par Light | Control Method: | Text Screen |
| High Light: | Text Screen Glue Dispensing Machine,PLC Glue Dispensing Machine,4 Rotary Stations Dispensing Machine |
||
| Model | HS-BD4 |
| MCU | Industrial PLC |
| Programming | Text Demonstration Programmer |
| Drive mode | Precise Stepping Motor |
| Max Dispensing Diameter | 160mm(two station),110mm(four station) |
| Motor Speed | 0 ~ 300 RPM |
| Positioning Accuracy | ±0.1mm |
| Z-axis Adjust Range | 250mm |
| Z-axis Working Travel | 50mm |
| Dimension (L*W*H) | 420mm*532mm*532mm |
| Weight | 35Kg |
| Working Power | AC220V/50~60Hz/200W |
| Working Air Pressure | 0.4~ 0.6Mpa(no condensation) |
| Working Temperature and Humidity | Temperature: 0~40℃,Humidity: 20~90% |
1, Four work stations in cycle, the designed capacity is 1000~1500pcs/h.
2, Equipped work piece detector to decide gluing or skip.
3, Gluing track can be set as full circle, single point or segmented arc etc.
4, Working mode can be four-station or two-station.
5, It is easy to learn and operate with touch screen and buttons, for different glue with different settings ensure the best performance.
About Us:
Shenzhen HanSome Technology Co.,Ltd(HSTECH)was estabilished in 2012 by prefessional and experienced engineer who wroked many years in EMS company,we specilized in PCB handling equipments at first, then we develop the PCB depaneling machine and SMT cleaning machine. HSTECH not only have professional technical team for R&D,but also have a outgoing and experienced marketing team for research and develop, grasps products developing directions, updates the products and technics to meet the continue changing demands. In the past years,we have been always keep innovating and exploing to make cost-efficient products to help our customers saving cost and labor, improving the production efficiency at the same time.
HSTECH set the goal for "High quality and Smart”, that based on the concept of "Quality-Oriented and Customer-orented", and combined the industry feature, smart technology persuit for the smart factory.As for the after-sale service, we insist on "responsibility", we will take reaction at the first when we got quality feedbacks,and service our customers all the time.
